This setting will control if these settings will be companywide or if they can be configured by individual users.Ĭreate configurations will add a new configuration to an existing toolbox file each time a new toolbox size is used. Smart fasteners settings control what hardware files from the toolbox are used when a user activates the smart fastener feature within Solidworks. These options do not pertain to any settings contained within Solidworks. The user settings only control the settings for the toolbox settings program. Editing Configuration names: These are the unique names generated by the program when the hardware is initialized for the first time.Part Numbers: This is an included property in each component, this is very similar to its custom property counterpart.Adding: This restricts users from adding custom Solidworks parts to the toolbox database.Custom properties: These are set by the user, these could include vendor, material, or various other trackable hardware information.Content: This is what pieces of hardware is available for use in the toolbox add-in within Solidworks.This limits the users from being able to make changes with unintended consequences.

CONFIGURE SOLIDWORKS TOOLBOX CODE

After this has been created all users wishing to change locked aspects will need the administration code to do so. To activate the toolbox permissions simply create a password and security phrase to lock the toolbox. Toolbox contains its own permission structure to limit individual user’s ability to edit specific parameters linked to the toolbox. As compared to having and incremental implementation. Ideally these would be set up before rollout. These functions, though powerful, must be configured up by the user(s).

The toolbox can populate bills of material, contain materials, and automatically be added to assemblies.

CONFIGURE SOLIDWORKS TOOLBOX UPDATE

Test functionality by launching the toolbox inside of Solidworks.Īfter the update check-in the database and have users get latest so the changes are reflected for all users. Once this is complete the toolbox will be updated. Run the update utility it’ll take several minutes. It will reference the folder used to launch the updater from, since this folder contains the updating information.īefore using the updater check out the database file swbrowser.sldedb, in the case a file named swbrowser.sldedbold is also found in the directory it will need to be checked out as well. The application will automatically fill out the updating database information. This is loaded from Solidworks, if this window is blank simply navigate to the database file “swbrowser.sldedb” it exists at \lang\english. First, it will display both the directory to the toolbox and its version. Once in the utility some information will be provided, and some will need to be selected. In this folder find and launch the application: “Update browser database”.

CONFIGURE SOLIDWORKS TOOLBOX HOW TO

Details on how to this can be found in “Migrating Toolbox files to a network location or PDM Vault.”

CONFIGURE SOLIDWORKS TOOLBOX INSTALL

It’s encouraged to install the toolbox in the PDM environment and setup the vault to manage the files within Toolbox. PDM standard and PDM professional are both built to manage Solidworks toolbox and its files.

Note: When utilizing PDM Standard or PDM Professional, the specific steps will be colored in blue. Setting up and using a toolbox can be broken into several distinct steps these are listed below These components can be configured to easily populate Bills of Material with part numbers descriptions or any other custom information that needs to be easily displayed to the user.

The Toolbox contains a vast library of standard hardware components that can easily be dropped into a design at any point. The Toolbox is a collection of several powerful tools built into SolidWorks it can increase productivity and decrease the time required to complete a design.
